KUBIK is a robust cube-shaped/rectangular-shaped spotlight/floodlight with LED and HID light source. The family offers ground/wall mount fixing, pole clamp and wall clamp array, indirect pole and indirect wall light. The front glass cover is flush to the luminaire housing thus dust and water are not accumulated. High-efficiency lenses and reflectors are used in this luminaire family. Aiming can be done through graduated scale by the tool. KUBIK is suitable to light up the object from short to medium distance for example bushes, plants, sculptures, flags, signboards, columns, building facets, playgrounds, open spaces etc. Full list of accessories is available as standard option.
Ordering Code : 5941-A-3-531-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : 12° | Lumen : 860 lm | CCT : 2700 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
Ordering Code : 5941-B-3-531-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : 25° | Lumen : 780 lm | CCT : 2700 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
Ordering Code : 5941-C-3-531-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : 46° | Lumen : 720 lm | CCT : 2700 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
Ordering Code : 5941-H-3-531-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Elliptical H | Lumen : 680 lm | CCT : 2700 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
Ordering Code : 5941-N-3-531-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Elliptical V | Lumen : 680 lm | CCT : 2700 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
Ordering Code : 5941-P-3-646-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Sharp Elliptical H | Lumen : 220 lm | CCT : 2700 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
Ordering Code : 5941-Q-3-646-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Sharp Elliptical V | Lumen : 220 lm | CCT : 2700 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-A-2-528-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : 12° | Lumen : 1200 lm | CCT : 2700 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-B-2-528-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : 25° | Lumen : 1080 lm | CCT : 2700 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-C-2-528-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : 46° | Lumen : 1000 lm | CCT : 2700 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-H-2-528-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Elliptical H | Lumen : 940 lm | CCT : 2700 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-N-2-528-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Elliptical V | Lumen : 940 lm | CCT : 2700 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-P-2-630-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Sharp Elliptical H | Lumen : 310 lm | CCT : 2700 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-Q-2-630-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Sharp Elliptical V | Lumen : 310 lm | CCT : 2700 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-A-3-532-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : 12° | Lumen : 860 lm | CCT : 3000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-B-3-532-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : 25° | Lumen : 780 lm | CCT : 3000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-C-3-532-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : 46° | Lumen : 720 lm | CCT : 3000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-H-3-532-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Elliptical H | Lumen : 680 lm | CCT : 3000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-N-3-532-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Elliptical V | Lumen : 680 lm | CCT : 3000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-P-3-647-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Sharp Elliptical H | Lumen : 220 lm | CCT : 3000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-Q-3-647-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Sharp Elliptical V | Lumen : 220 lm | CCT : 3000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-A-2-529-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : 12° | Lumen : 1200 lm | CCT : 3000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-B-2-529-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : 25° | Lumen : 1080 lm | CCT : 3000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-C-2-529-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : 46° | Lumen : 1000 lm | CCT : 3000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-H-2-529-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Elliptical H | Lumen : 940 lm | CCT : 3000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-N-2-529-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Elliptical V | Lumen : 940 lm | CCT : 3000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-P-2-644-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Sharp Elliptical H | Lumen : 310 lm | CCT : 3000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-Q-2-644-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Sharp Elliptical V | Lumen : 310 lm | CCT : 3000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
Ordering Code : 5941-0-3-915-XX
|
Lamp : LED | Socket : N/A | Wattage : 22 W | Beam : 15° | Lumen : 1660 lm | CCT : 3000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
Ordering Code : 5941-0-3-916-XX
|
Lamp : LED | Socket : N/A | Wattage : 22 W | Beam : 25° | Lumen : 1590 lm | CCT : 3000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
Ordering Code : 5941-0-3-917-XX
|
Lamp : LED | Socket : N/A | Wattage : 22 W | Beam : 38° | Lumen : 1610 lm | CCT : 3000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-A-3-533-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : 12° | Lumen : 920 lm | CCT : 4000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-B-3-533-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : 25° | Lumen : 830 lm | CCT : 4000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-C-3-533-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : 46° | Lumen : 770 lm | CCT : 4000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-H-3-533-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Elliptical H | Lumen : 720 lm | CCT : 4000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-N-3-533-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Elliptical V | Lumen : 720 lm | CCT : 4000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-P-3-648-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Sharp Elliptical H | Lumen : 230 lm | CCT : 4000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-Q-3-648-XX
|
Lamp : LED | Socket : N/A | Wattage : 10 W | Beam : Sharp Elliptical V | Lumen : 230 lm | CCT : 4000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-A-2-530-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : 12° | Lumen : 1290 lm | CCT : 4000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-B-2-530-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : 25° | Lumen : 1170 lm | CCT : 4000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-C-2-530-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : 46° | Lumen : 1080 lm | CCT : 4000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-H-2-530-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Elliptical H | Lumen : 1020 lm | CCT : 4000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-N-2-530-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Elliptical V | Lumen : 1020 lm | CCT : 4000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data DownloadAccessories
0405-0-9-000-00
|
||||||||
|
Ordering Code : 5941-P-2-645-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Sharp Elliptical H | Lumen : 330 lm | CCT : 4000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-Q-2-645-XX
|
Lamp : LED | Socket : N/A | Wattage : 15 W | Beam : Sharp Elliptical V | Lumen : 330 lm | CCT : 4000 K | Controller : Remote driver On-Off / DIM 1-10V / DALI | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-0-3-918-XX
|
Lamp : LED | Socket : N/A | Wattage : 22 W | Beam : 15° | Lumen : 1780 lm | CCT : 4000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-0-3-919-XX
|
Lamp : LED | Socket : N/A | Wattage : 22 W | Beam : 25° | Lumen : 1710 lm | CCT : 4000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
|
Ordering Code : 5941-0-3-920-XX
|
Lamp : LED | Socket : N/A | Wattage : 22 W | Beam : 38° | Lumen : 1720 lm | CCT : 4000 K | Controller : On-Off | |
.jpg "Mini KUBIK - Ground Mount")
Technical Data Download |
||||||||
