ZET Square Opal

ZET walk-over in ground uplighter with fixed and adjustable optic utilized high-performance LED with additional glare control accessory to deliver the best and comfortable light distribution. ZET Adjustable is available in COB LED or High Power LED with various beam angle option. It is supplied with a post-cured silicone gasket with pre-wire cable for outdoor use. ZET is commonly used to highlight architectural tasks, wall structures, low ceilings, and columns. The glare-shield honey comb and softening lens are available as accessories. A gel-filled IP68 connection device for water tight connection is also available as standard option. Retrofit solution with GU5.3 or GU10 Led lamp base is presented in this family. The installation of this product and drainage system must be done according to the product’s manual.


Ordering Code : 9004-0-7-586-91
Lamp : LED Socket : N/A Wattage : 8.1 W Beam : N/A Lumen : 210 lm CCT : 2700 K Controller : On-Off / DALI Specsheet :
ZET Square Opal - CVDA
ZET Square Opal - CVDA

Accessories

AUN-DRG-0011-00
LED constant voltage driver, 24VDC, 150W
AUN-CON-0014-00
IP68 connection device, cable diameter 8-12.5mm, 1-10V or DALI
AUN-DRG-0027-00
LED constant voltage driver, 24VDC, 72W
Ordering Code : 9004-0-2-528-91
Lamp : LED Socket : N/A Wattage : 13 W Beam : N/A Lumen : 300 lm CCT : 2700 K Controller : Remote Specsheet :
ZET Square Opal
ZET Square Opal

Accessories

AUN-DRG-0004-01
LED constant current driver, 1050mA, 22W, with IP67 GFR polymer enclosure, On-Off
AUN-DRG-0006-01
LED constant current driver, 1050mA, 38W, with IP67 GFR polymer enclosure, DALI
AUN-CON-0013-00
IP68 connection device, cable diameter 7-11.5mm, On-Off
AUN-CON-0004-00
IP68 Connector, cable diameter 8-10mm, gel-filled
AUN-DRG-0021-00
LED constant current driver, 1050mA, 38W, with IP67 GFR polymer enclosure, 1-10V
Ordering Code : 9004-0-7-583-91
Lamp : LED Socket : N/A Wattage : 13 W Beam : N/A Lumen : 300 lm CCT : 2700 K Controller : On-Off / DALI Specsheet :
ZET Square Opal - CVDA
ZET Square Opal - CVDA

Accessories

AUN-DRG-0011-00
LED constant voltage driver, 24VDC, 150W
AUN-CON-0014-00
IP68 connection device, cable diameter 8-12.5mm, 1-10V or DALI
AUN-DRG-0027-00
LED constant voltage driver, 24VDC, 72W
Ordering Code : 9004-0-7-587-91
Lamp : LED Socket : N/A Wattage : 8.1 W Beam : N/A Lumen : 210 lm CCT : 3000 K Controller : On-Off / DALI Specsheet :
ZET Square Opal - CVDA
ZET Square Opal - CVDA

Accessories

AUN-DRG-0011-00
LED constant voltage driver, 24VDC, 150W
AUN-CON-0014-00
IP68 connection device, cable diameter 8-12.5mm, 1-10V or DALI
AUN-DRG-0027-00
LED constant voltage driver, 24VDC, 72W
Ordering Code : 9004-0-3-869-91
Lamp : LED Socket : N/A Wattage : 11 W Beam : N/A Lumen : 150 lm CCT : 3000 K Controller : On-Off (AC LED) Specsheet :
ZET Square Opal
ZET Square Opal

Accessories

AUN-CON-0013-00
IP68 connection device, cable diameter 7-11.5mm, On-Off
AUN-RCH-0005-00
Recessed installation housing
AUN-CON-0004-00
IP68 Connector, cable diameter 8-10mm, gel-filled
Ordering Code : 9004-0-2-529-91
Lamp : LED Socket : N/A Wattage : 13 W Beam : N/A Lumen : 300 lm CCT : 3000 K Controller : Remote Specsheet :
ZET Square Opal
ZET Square Opal

Accessories

AUN-DRG-0004-01
LED constant current driver, 1050mA, 22W, with IP67 GFR polymer enclosure, On-Off
AUN-DRG-0006-01
LED constant current driver, 1050mA, 38W, with IP67 GFR polymer enclosure, DALI
AUN-CON-0013-00
IP68 connection device, cable diameter 7-11.5mm, On-Off
AUN-CON-0004-00
IP68 Connector, cable diameter 8-10mm, gel-filled
AUN-DRG-0021-00
LED constant current driver, 1050mA, 38W, with IP67 GFR polymer enclosure, 1-10V
Ordering Code : 9004-0-7-584-91
Lamp : LED Socket : N/A Wattage : 13 W Beam : N/A Lumen : 300 lm CCT : 3000 K Controller : On-Off / DALI Specsheet :
ZET Square Opal - CVDA
ZET Square Opal - CVDA

Accessories

AUN-DRG-0011-00
LED constant voltage driver, 24VDC, 150W
AUN-CON-0014-00
IP68 connection device, cable diameter 8-12.5mm, 1-10V or DALI
AUN-DRG-0027-00
LED constant voltage driver, 24VDC, 72W
Ordering Code : 9004-0-7-588-91
Lamp : LED Socket : N/A Wattage : 8.1 W Beam : N/A Lumen : 230 lm CCT : 4000 K Controller : On-Off / DALI Specsheet :
ZET Square Opal - CVDA
ZET Square Opal - CVDA

Accessories

AUN-DRG-0011-00
LED constant voltage driver, 24VDC, 150W
AUN-CON-0014-00
IP68 connection device, cable diameter 8-12.5mm, 1-10V or DALI
AUN-DRG-0027-00
LED constant voltage driver, 24VDC, 72W
Ordering Code : 9004-0-2-920-91
Lamp : LED Socket : N/A Wattage : 11 W Beam : N/A Lumen : 540 lm CCT : 4000 K Controller : Remote driver CC On-Off Specsheet :
ZET Square Opal
ZET Square Opal

Accessories

AUN-DRG-0003-01
LED constant current driver, 350mA, 15W, with IP67 GFR polymer enclosure, On-Off
AUN-RCH-0005-00
Recessed installation housing
AUN-CON-0007-00
IP68 distribution box, series wiring , for 1-3 luminaires
AUN-CON-0004-00
IP68 Connector, cable diameter 8-10mm, gel-filled
Ordering Code : 9004-0-3-870-91
Lamp : LED Socket : N/A Wattage : 10 W Beam : N/A Lumen : 150 lm CCT : 4000 K Controller : On-Off (AC LED) Specsheet :
ZET Square Opal
ZET Square Opal

Accessories

AUN-CON-0013-00
IP68 connection device, cable diameter 7-11.5mm, On-Off
AUN-RCH-0005-00
Recessed installation housing
AUN-CON-0004-00
IP68 Connector, cable diameter 8-10mm, gel-filled
Ordering Code : 9004-0-2-530-91
Lamp : LED Socket : N/A Wattage : 13 W Beam : N/A Lumen : 330 lm CCT : 4000 K Controller : Remote Specsheet :
ZET Square Opal
ZET Square Opal

Accessories

AUN-DRG-0004-01
LED constant current driver, 1050mA, 22W, with IP67 GFR polymer enclosure, On-Off
AUN-DRG-0006-01
LED constant current driver, 1050mA, 38W, with IP67 GFR polymer enclosure, DALI
AUN-CON-0013-00
IP68 connection device, cable diameter 7-11.5mm, On-Off
AUN-CON-0004-00
IP68 Connector, cable diameter 8-10mm, gel-filled
AUN-DRG-0021-00
LED constant current driver, 1050mA, 38W, with IP67 GFR polymer enclosure, 1-10V
Ordering Code : 9004-0-7-585-91
Lamp : LED Socket : N/A Wattage : 13 W Beam : N/A Lumen : 330 lm CCT : 4000 K Controller : On-Off / DALI Specsheet :
ZET Square Opal - CVDA
ZET Square Opal - CVDA

Accessories

AUN-DRG-0011-00
LED constant voltage driver, 24VDC, 150W
AUN-CON-0014-00
IP68 connection device, cable diameter 8-12.5mm, 1-10V or DALI
AUN-DRG-0027-00
LED constant voltage driver, 24VDC, 72W
Ordering Code : 9004-0-2-221-91
Lamp : QPAR51 Socket : GU10 Wattage : N/A Beam : 40°,84° Lumen : 600 lm CCT : 2900 K Controller : On-Off Specsheet :
ZET Square Opal
ZET Square Opal

Accessories

AUN-CON-0013-00
IP68 connection device, cable diameter 7-11.5mm, On-Off
AUN-SOF-0006-00
Softening lens, Halogen, pre-assembly from factory
AUN-RCH-0005-00
Recessed installation housing
AUN-CON-0004-00
IP68 Connector, cable diameter 8-10mm, gel-filled
Ordering Code : 9004-0-2-281-91
Lamp : QR-CB51 Socket : GU5.3 Wattage : N/A Beam : 45° Lumen : 990 lm CCT : 3200 K Controller : Remote Specsheet :
ZET Square Opal
ZET Square Opal

Accessories

AUN-DRG-0115-01
Electronic Transformer, 12V, 20-60W, with IP67 GFR polymer enclosure
AUN-CON-0013-00
IP68 connection device, cable diameter 7-11.5mm, On-Off
AUN-SOF-0006-00
Softening lens, Halogen, pre-assembly from factory
AUN-GSH-0002-01
Honeycomb louver, QR-CB51, pre-assembly from factory
AUN-RCH-0005-00
Recessed installation housing
AUN-CON-0004-00
IP68 Connector, cable diameter 8-10mm, gel-filled
