ZET1 - Frost

ZET walk-over in ground uplighter with fixed and adjustable optic utilized high-performance LED with additional glare control accessory to deliver the best and comfortable light distribution. ZET Adjustable is available in COB LED or High Power LED with various beam angle option. It is supplied with a post-cured silicone gasket with pre-wire cable for outdoor use. ZET is commonly used to highlight architectural tasks, wall structures, low ceilings, and columns. The glare-shield honey comb and softening lens are available as accessories. A gel-filled IP68 connection device for water tight connection is also available as standard option. Retrofit solution with GU5.3 or GU10 Led lamp base is presented in this family. The installation of this product and drainage system must be done according to the product’s manual.


Ordering Code : 9002-0-2-522-91
Lamp : LED Socket : N/A Wattage : 11 W Beam : N/A Lumen : 570 lm CCT : 2700 K Controller : Remote driver On-Off
ZET1 - Frost
ZET1 - Frost

Accessories

0248-0-9-000-00
IP68 Water Tight Connecting Device Cable Diameter 7 - 12mm.
0275-0-9-000-01
LED Constant Current Driver 350mA 1-15W. In IP67 GFR Polymer Box
0181-0-9-000-00
Deeper Ground Recess Housing
0138-0-9-000-00
IP68 Water Tight Connection Device for Through Wiring
0258-0-9-000-00
IP68 'Series-Wiring' LED Distribution Box for 1-3 Luminaires
0246-0-9-000-00
Gel-Filled IP68 Connector Cable Diameter 8 - 10mm
0245-0-9-000-00
Gel-Filled IP68 Connector for Through Wiring Cable Diameter 6.5 - 12mm.
Ordering Code : 9002-0-2-528-91
Lamp : LED Socket : N/A Wattage : 14 W Beam : N/A Lumen : 300 lm CCT : 2700 K Controller : Remote driver On-Off / DIM 1-10V / DALI
ZET1 - Frost
ZET1 - Frost

Accessories

0248-0-9-000-00
IP68 Water Tight Connecting Device Cable Diameter 7 - 12mm.
0402-0-9-000-01
LED Constant Current Driver 1050mA 22W. In IP67 GFR Polymer Box
0403-0-9-000-01
LED Constant Current Driver 700mA 20W. In IP67 GFR Polymer Box (DIM 1-10V)
0404-0-9-000-01
LED Constant Current Driver 1050mA 38W. In IP67 GFR Polymer Box (DALI)
0138-0-9-000-00
IP68 Water Tight Connection Device for Through Wiring
0246-0-9-000-00
Gel-Filled IP68 Connector Cable Diameter 8 - 10mm
0245-0-9-000-00
Gel-Filled IP68 Connector for Through Wiring Cable Diameter 6.5 - 12mm.
Ordering Code : 9002-0-2-917-91
Lamp : LED Socket : N/A Wattage : 11 W Beam : N/A Lumen : 540 lm CCT : 3000 K Controller : Remote driver On-Off
ZET1 - Frost
ZET1 - Frost

Accessories

0248-0-9-000-00
IP68 Water Tight Connecting Device Cable Diameter 7 - 12mm.
0275-0-9-000-01
LED Constant Current Driver 350mA 1-15W. In IP67 GFR Polymer Box
0181-0-9-000-00
Deeper Ground Recess Housing
0138-0-9-000-00
IP68 Water Tight Connection Device for Through Wiring
0258-0-9-000-00
IP68 'Series-Wiring' LED Distribution Box for 1-3 Luminaires
0246-0-9-000-00
Gel-Filled IP68 Connector Cable Diameter 8 - 10mm
0245-0-9-000-00
Gel-Filled IP68 Connector for Through Wiring Cable Diameter 6.5 - 12mm.
Ordering Code : 9002-0-2-529-91
Lamp : LED Socket : N/A Wattage : 14 W Beam : N/A Lumen : 300 lm CCT : 3000 K Controller : Remote driver On-Off / DIM 1-10V / DALI
ZET1 - Frost
ZET1 - Frost

Accessories

0248-0-9-000-00
IP68 Water Tight Connecting Device Cable Diameter 7 - 12mm.
0402-0-9-000-01
LED Constant Current Driver 1050mA 22W. In IP67 GFR Polymer Box
0403-0-9-000-01
LED Constant Current Driver 700mA 20W. In IP67 GFR Polymer Box (DIM 1-10V)
0404-0-9-000-01
LED Constant Current Driver 1050mA 38W. In IP67 GFR Polymer Box (DALI)
0138-0-9-000-00
IP68 Water Tight Connection Device for Through Wiring
0246-0-9-000-00
Gel-Filled IP68 Connector Cable Diameter 8 - 10mm
0245-0-9-000-00
Gel-Filled IP68 Connector for Through Wiring Cable Diameter 6.5 - 12mm.
Ordering Code : 9002-0-2-920-91
Lamp : LED Socket : N/A Wattage : 11 W Beam : N/A Lumen : 540 lm CCT : 4000 K Controller : Remote driver On-Off
ZET1 - Frost
ZET1 - Frost

Accessories

0248-0-9-000-00
IP68 Water Tight Connecting Device Cable Diameter 7 - 12mm.
0275-0-9-000-01
LED Constant Current Driver 350mA 1-15W. In IP67 GFR Polymer Box
0181-0-9-000-00
Deeper Ground Recess Housing
0138-0-9-000-00
IP68 Water Tight Connection Device for Through Wiring
0258-0-9-000-00
IP68 'Series-Wiring' LED Distribution Box for 1-3 Luminaires
0246-0-9-000-00
Gel-Filled IP68 Connector Cable Diameter 8 - 10mm
0245-0-9-000-00
Gel-Filled IP68 Connector for Through Wiring Cable Diameter 6.5 - 12mm.
Ordering Code : 9002-0-3-870-91
Lamp : LED Socket : N/A Wattage : 10 W Beam : N/A Lumen : 150 lm CCT : 4000 K Controller : On-Off (AC LED)
ZET1 - Frost
ZET1 - Frost

Accessories

0248-0-9-000-00
IP68 Water Tight Connecting Device Cable Diameter 7 - 12mm.
0181-0-9-000-00
Deeper Ground Recess Housing
0138-0-9-000-00
IP68 Water Tight Connection Device for Through Wiring
0246-0-9-000-00
Gel-Filled IP68 Connector Cable Diameter 8 - 10mm
0245-0-9-000-00
Gel-Filled IP68 Connector for Through Wiring Cable Diameter 6.5 - 12mm.
Ordering Code : 9002-0-2-530-91
Lamp : LED Socket : N/A Wattage : 14 W Beam : N/A Lumen : 330 lm CCT : 4000 K Controller : Remote driver On-Off / DIM 1-10V / DALI
ZET1 - Frost
ZET1 - Frost

Accessories

0248-0-9-000-00
IP68 Water Tight Connecting Device Cable Diameter 7 - 12mm.
0402-0-9-000-01
LED Constant Current Driver 1050mA 22W. In IP67 GFR Polymer Box
0403-0-9-000-01
LED Constant Current Driver 700mA 20W. In IP67 GFR Polymer Box (DIM 1-10V)
0404-0-9-000-01
LED Constant Current Driver 1050mA 38W. In IP67 GFR Polymer Box (DALI)
0138-0-9-000-00
IP68 Water Tight Connection Device for Through Wiring
0246-0-9-000-00
Gel-Filled IP68 Connector Cable Diameter 8 - 10mm
0245-0-9-000-00
Gel-Filled IP68 Connector for Through Wiring Cable Diameter 6.5 - 12mm.
Ordering Code : 9002-0-2-221-91
Lamp : QPAR51 Socket : GU10 Wattage : 50 W Beam : 40°,84° Lumen : 600 lm CCT : 2900 K Controller : On-Off
ZET1 - Frost
ZET1 - Frost

Accessories

0248-0-9-000-00
IP68 Water Tight Connecting Device Cable Diameter 7 - 12mm.
0009-0-9-000-00
Softening Lens for Halogen lamp
0181-0-9-000-00
Deeper Ground Recess Housing
0138-0-9-000-00
IP68 Water Tight Connection Device for Through Wiring
0246-0-9-000-00
Gel-Filled IP68 Connector Cable Diameter 8 - 10mm
0245-0-9-000-00
Gel-Filled IP68 Connector for Through Wiring Cable Diameter 6.5 - 12mm.
Ordering Code : 9002-0-2-281-91
Lamp : QR-CB51 Socket : GU5.3 Wattage : 50 W Beam : 45° Lumen : 990 lm CCT : 3200 K Controller : Remote transformer
ZET1 - Frost
ZET1 - Frost

Accessories

0248-0-9-000-00
IP68 Water Tight Connecting Device Cable Diameter 7 - 12mm.
0277-0-9-000-01
Electronic Transformer 12V 20-60W in IP67 GFR Polymer Box
0009-0-9-000-00
Softening Lens for Halogen lamp
0257-0-9-000-01
Honey Comb Louver for QR-CB51 lamp
0181-0-9-000-00
Deeper Ground Recess Housing
0138-0-9-000-00
IP68 Water Tight Connection Device for Through Wiring
0246-0-9-000-00
Gel-Filled IP68 Connector Cable Diameter 8 - 10mm
0245-0-9-000-00
Gel-Filled IP68 Connector for Through Wiring Cable Diameter 6.5 - 12mm.
