Mini ANDROMEDA

ANDROMEDA is a round-shaped robust outdoor luminaire for public space illumination. The housing is made of corrosion resistant LM6 die-cast aluminium and is passivated with Nano Ceramic layer then coated with primer and super durable Polyester powder paint. ANDROMEDA is equipped with high power LEDs with high CRI in 3000K or 4000K color temperature with 3 SDCM. It offers perfectly engineered light distributions for various lighting applications such as area lighting, car parks, open spaces and façade lighting. ANDROMEDA fulfills the dark sky requirement and is free from light pollution. The heat management has been delicately designed and tested under high ambient thermal condition. An integrated scale allows precise aiming of the luminaire to achieve the desired illumination level. The recommended mounting height is between 4 – 8 meters depending on the application. Available as an option are Aluminium Poles, Galvanized steel poles and anchorage unit for concrete foundations.


Ordering Code : 7297-2-3-863-XX
Lamp : LED Socket : N/A Wattage : 62 W Beam : 95° Lumen : 6170 lm CCT : 3000 K Controller : On-Off Specsheet :
Mini ANDROMEDA
Mini ANDROMEDA

Accessories

ALUMINUM-POLE-MINI-ANDROMEDA
Please contact Sales Representative
STEEL-POLE-MINI-ANDROMEDA
Please contact Sales Representative
AUN-ACB-0009-00
Anchor bolt kit, pole diameter 114 and 114/140, galvanized steel pole
AUN-ACB-0008-00
Anchor bolt kit, pole diameter 102mm and 151x102mm, galvanized steel pole
AUN-ACB-0005-00
Anchor bolt kit, aluminum pole
Ordering Code : 7297-1-3-863-XX
Lamp : LED Socket : N/A Wattage : 62 W Beam : Asymmetric Lumen : 6120 lm CCT : 3000 K Controller : On-Off Specsheet :
Mini ANDROMEDA
Mini ANDROMEDA

Accessories

ALUMINUM-POLE-MINI-ANDROMEDA
Please contact Sales Representative
STEEL-POLE-MINI-ANDROMEDA
Please contact Sales Representative
AUN-ACB-0009-00
Anchor bolt kit, pole diameter 114 and 114/140, galvanized steel pole
AUN-ACB-0008-00
Anchor bolt kit, pole diameter 102mm and 151x102mm, galvanized steel pole
AUN-ACB-0005-00
Anchor bolt kit, aluminum pole
Ordering Code : 7297-9-3-863-XX
Lamp : LED Socket : N/A Wattage : 62 W Beam : Road Optic Lumen : 5830 lm CCT : 3000 K Controller : On-Off Specsheet :
Mini ANDROMEDA
Mini ANDROMEDA

Accessories

ALUMINUM-POLE-MINI-ANDROMEDA
Please contact Sales Representative
STEEL-POLE-MINI-ANDROMEDA
Please contact Sales Representative
AUN-ACB-0009-00
Anchor bolt kit, pole diameter 114 and 114/140, galvanized steel pole
AUN-ACB-0008-00
Anchor bolt kit, pole diameter 102mm and 151x102mm, galvanized steel pole
AUN-ACB-0005-00
Anchor bolt kit, aluminum pole
Ordering Code : 7297-1-3-861-XX
Lamp : LED Socket : N/A Wattage : 87 W Beam : Asymmetric Lumen : 8190 lm CCT : 3000 K Controller : On-Off Specsheet :
Mini ANDROMEDA
Mini ANDROMEDA

Accessories

ALUMINUM-POLE-MINI-ANDROMEDA
Please contact Sales Representative
STEEL-POLE-MINI-ANDROMEDA
Please contact Sales Representative
AUN-ACB-0009-00
Anchor bolt kit, pole diameter 114 and 114/140, galvanized steel pole
AUN-ACB-0008-00
Anchor bolt kit, pole diameter 102mm and 151x102mm, galvanized steel pole
AUN-ACB-0005-00
Anchor bolt kit, aluminum pole
Ordering Code : 7297-9-3-864-XX
Lamp : LED Socket : N/A Wattage : 62 W Beam : Road Optic Lumen : 6780 lm CCT : 4000 K Controller : On-Off Specsheet :
Mini ANDROMEDA
Mini ANDROMEDA

Accessories

ALUMINUM-POLE-MINI-ANDROMEDA
Please contact Sales Representative
STEEL-POLE-MINI-ANDROMEDA
Please contact Sales Representative
AUN-ACB-0009-00
Anchor bolt kit, pole diameter 114 and 114/140, galvanized steel pole
AUN-ACB-0008-00
Anchor bolt kit, pole diameter 102mm and 151x102mm, galvanized steel pole
AUN-ACB-0005-00
Anchor bolt kit, aluminum pole
Ordering Code : 7297-1-5-862-XX
Lamp : LED Socket : N/A Wattage : 87 W Beam : Asymmetric Lumen : 9500 lm CCT : 4000 K Controller : DALI Specsheet :
Mini ANDROMEDA
Mini ANDROMEDA

Accessories

ALUMINUM-POLE-MINI-ANDROMEDA
Please contact Sales Representative
STEEL-POLE-MINI-ANDROMEDA
Please contact Sales Representative
AUN-ACB-0009-00
Anchor bolt kit, pole diameter 114 and 114/140, galvanized steel pole
AUN-ACB-0008-00
Anchor bolt kit, pole diameter 102mm and 151x102mm, galvanized steel pole
AUN-ACB-0005-00
Anchor bolt kit, aluminum pole
Ordering Code : 7297-9-5-862-XX
Lamp : LED Socket : N/A Wattage : 87 W Beam : Road Optic Lumen : 9040 lm CCT : 4000 K Controller : DALI Specsheet :
Mini ANDROMEDA
Mini ANDROMEDA

Accessories

ALUMINUM-POLE-MINI-ANDROMEDA
Please contact Sales Representative
STEEL-POLE-MINI-ANDROMEDA
Please contact Sales Representative
AUN-ACB-0009-00
Anchor bolt kit, pole diameter 114 and 114/140, galvanized steel pole
AUN-ACB-0008-00
Anchor bolt kit, pole diameter 102mm and 151x102mm, galvanized steel pole
AUN-ACB-0005-00
Anchor bolt kit, aluminum pole
