Mini CAP - Short Bollard Root Mount Base

The CAP range is a fresh range of bollards and low mounted pole lights. Designed from scratch with the latest lighting requirements in mind. The highly efficient LEDs are shielded and emit no upward light. The light engine features great color consistency, excellent color rendering index and dimming options. Specification grade optics make the medium sized version a highly competitive lighting tool for demanding professional lighting tasks. With its compact dimensions the small sized CAP is a smart solution for residential lighting projects. Regardless of size the prewired supply cable, numerous mounting solutions and minimized amount of screws assure a simplified installation process.


Ordering Code : 7878-0-3-574-XX
Lamp : LED Socket : N/A Wattage : 7 W Beam : N/A Lumen : 640 lm CCT : 2700 K Controller : On-Off Specsheet :
Mini CAP - Short Bollard Root Mount Base
Mini CAP - Short Bollard Root Mount Base

Accessories

AUN-CON-0013-00
IP68 Water Tight Connecting Device, 3 Pole, Cable Diameter 7 - 11.5mm.
Ordering Code : 7878-0-3-560-XX
Lamp : LED Socket : N/A Wattage : 9 W Beam : N/A Lumen : 930 lm CCT : 2700 K Controller : On-Off Specsheet :
Mini CAP - Short Bollard Root Mount Base
Mini CAP - Short Bollard Root Mount Base

Accessories

AUN-CON-0013-00
IP68 Water Tight Connecting Device, 3 Pole, Cable Diameter 7 - 11.5mm.
Ordering Code : 7878-0-3-575-XX
Lamp : LED Socket : N/A Wattage : 7 W Beam : N/A Lumen : 670 lm CCT : 3000 K Controller : On-Off Specsheet :
Mini CAP - Short Bollard Root Mount Base
Mini CAP - Short Bollard Root Mount Base

Accessories

AUN-CON-0013-00
IP68 Water Tight Connecting Device, 3 Pole, Cable Diameter 7 - 11.5mm.
Ordering Code : 7878-0-3-921-XX
Lamp : LED Socket : N/A Wattage : 9 W Beam : N/A Lumen : 950 lm CCT : 3000 K Controller : On-Off Specsheet :
Mini CAP - Short Bollard Root Mount Base
Mini CAP - Short Bollard Root Mount Base

Accessories

AUN-CON-0013-00
IP68 Water Tight Connecting Device, 3 Pole, Cable Diameter 7 - 11.5mm.
Ordering Code : 7878-0-3-576-XX
Lamp : LED Socket : N/A Wattage : 7 W Beam : N/A Lumen : 720 lm CCT : 4000 K Controller : On-Off Specsheet :
Mini CAP - Short Bollard Root Mount Base
Mini CAP - Short Bollard Root Mount Base

Accessories

AUN-CON-0013-00
IP68 Water Tight Connecting Device, 3 Pole, Cable Diameter 7 - 11.5mm.
Ordering Code : 7878-0-3-922-XX
Lamp : LED Socket : N/A Wattage : 9 W Beam : N/A Lumen : 1010 lm CCT : 4000 K Controller : On-Off Specsheet :
Mini CAP - Short Bollard Root Mount Base
Mini CAP - Short Bollard Root Mount Base

Accessories

AUN-CON-0013-00
IP68 Water Tight Connecting Device, 3 Pole, Cable Diameter 7 - 11.5mm.
